Laser triangulation sensor

Laser triangulation sensor for accurate distance determination

The project objective was the development of a priceoptimized laser triangulation sensor for non-contact distance measurement. In addition, the power supply and data transfer should realized via a USB interface.

Print Friendly, PDF & Email
Laser triangulation sensor, Optical measurement methods

Facts &
Highlights

  • Updates via USB interface directly possible
  • Dimensions: L x W x H = 75 x 65 x 25 mm
  • 5 V power supply via USB
  • Temperature range 0 to 40°C (32 to 104°F)
  • Measuring range: 80 mm to 140 mm
  • Accuracy: ± 0,2 mm

areas of application

areas of application

  • High-precision distance measurement in various areas
  • Range monitoring by combination with swivel motor
  • Measuring ranges and accuracies customizable
